Quartz Tube OD 10–19mm | Industrial Fused Silica Pipe 93% Visible Transmittance 1100℃ Heat Resistant for IR Heater Sight Glass

Quartz Tube OD 10–19mm | Industrial Fused Silica Pipe 93% Visible Transmittance 1100℃ Heat Resistant for IR Heater Sight Glass

$15.40 USD
$19.25 USD $15.40 USD
Sale Sold out
Shipping calculated at checkout.

Transportation time and requirements

SIZE
QTY

Quartz Tube OD10–19mm | Universal Industrial Fused Silica Pipe
Parameter
Specification
Outer Diameter
10mm - 19mm
Wall Thickness
1.0mm - 2.5mm
Dimensional Tolerance
±0.05mm - ±0.1mm
Custom Length
1000mm / 1500mm OEM Custom
SiO₂ Purity
≥99.95%
Long-term Working Temp
1100℃ Constant Heat Resistance
Visible Light Transmittance
≥93%, Bubble Grade 0-1
Core Performance: Superior acid corrosion resistance (150x stainless steel), anti-thermal shock, stable high-temperature dielectric insulation
Application: Infrared heating tube, chemical sight glass, lab reactor, semiconductor auxiliary parts
